    32U Outdoor Power Distribution Cabinet With 19inch Racked PDU And Cooling

    Ask Lasest Price
    Brand Name : daxin
    Model Number : DX-75751750
    Certification : CE,UL
    Payment Terms : L/C, T/T
    Supply Ability : 10000pcs/month
    • Product Details
    • Company Profile

    32U Outdoor Power Distribution Cabinet With 19inch Racked PDU And Cooling


    32U Outdoor Power Distribution Cabinet With 19inch Racked PDU And Cooling

    The 32U Integrated Power Cabinet is a highly adaptable solution for a wide range of applications, including telecommunications, data centers, industrial automation, renewable energy, and more. Its robust design, high protection level, and scalable rack space make it an ideal choice for both indoor and outdoor installations where reliability, security, and durability are critical.


    Cabinet Parameter

    Parameter

    Specification

    Cabinet Outer Dimensions

    W × D × H: 650 × 550 × 1800 mm

    Cabinet Composition

    Cabinet body + cabinet door + base + top cover + rack + cabinet lock

    Cabinet Type

    1 unit 1 compartment, front door, floor installation

    Cabinet Material

    1.5mm galvanized sheet

    Thermal Insulation

    Thermal conductivity < 0.472 W/(m²·K)

    Equipment Shelf

    19-inch rack, H: 32U, 3 pairs of support bars

    Cabinet Base

    100mm high, 2.0mm thick

    Cable Entry

    Bottom in and bottom out

    Anti-Theft Design

    Embedded door, embedded link, point anti-theft lock

    Protection Level

    IP55

    Color

    RAL7035, professional outdoor powder coating

    Logo

    Printed with "Electricity Danger" logo

    Additional Features

    Grounding copper bus, LED light, door magnetic switch, cooling fan (optional)


    More details:


    Power Cabinet Technique Parameter
    ItemName/DescriptionSpecifications/ModelsParameter
    1Outdoor integrated power cabinetW750*D750*H1750mm

    A. Cabinet outer dimensions: W×DxH650*550*1800mm
    B. Cabinet composition: cabinet body + cabinet door + base + top cover + rack + cabinet lock
    C. Cabinet type: 1 unit 1 compartment, front door, floor installation
    D. Cabinet material: 1.5mm galvanized sheet;

    E. Thermal insulation performance: thermal conductivity <0.472W/(m2.k);

    F. Equipment shelf: 19-inch rack,
    H:32U 3 pairs of support bars, 1 tray;
    G. Cabinet base: 100mm high, 2.0mm thick;
    H. Cable entry: bottom in and bottom out φ50*4;
    I. Anti-theft design: embedded door, embedded link, point anti-theft lock;
    J. Protection level: IP55;
    K. Color: RAL7035, professional outdoor powder coating;
    L. The cabinet is printed with "Electricity Danger" logo;
    M. Contains grounding copper bus, LED light, door magnetic switch, cooling fan (optional)

    2Power distribution unit3U19-inch 3U high embedded frame, AC380V input, 63A/4P×2 , three-phase Class B lightning arrester×1, 63A/3P×1, 32A/1P×2, 16A/1P×2, 10A/1P×1, 6A/1P×1, three-hole maintenance socket×1, ground row×1, zero row×1.
    3AC Air Conditioner1500WMounted on the front door


    32U Outdoor Power Distribution Cabinet With 19inch Racked PDU And Cooling32U Outdoor Power Distribution Cabinet With 19inch Racked PDU And Cooling32U Outdoor Power Distribution Cabinet With 19inch Racked PDU And Cooling
