    UPS

    Ask Lasest Price
    Brand Name : daxin
    Model Number : DX-1K
    Certification : CE,UL
    Payment Terms : T/T,Western Union
    Supply Ability : 10000pcs/month
    • Product Details
    • Company Profile

    UPS

    400VA, 600VA, 800VA, 1KVA, 1.5KVA, 2KVA, 3KVA
    line interactive UPS
    • Touch screen LCD to display UPS information circularly (option)
    • Compact size
    • Boost and buck AVR for voltage stabilization
    • Auto restart while AC is recovering
    • Off-mode charging
    • Cold start function
    • Generator compatible (option)
    • No load shutdown in battery mode for 800VA and
    below models.
    Apex 1K, 1.5K, 2K • Optional HID Power Device USB port


    Line Interactive UPS Selection Guide

    MODELApex 400Apex 600Apex 800Apex 1kApex 1.5kApex 2kApex 3k
    CAPACITY400VA/240W600VA/360W800VA/480W1000VA/600W1500VA/900W2000VA/1200W3000VA/1800W
    INPUT
    Voltage110/120 VAC or 220/230/240 VAC220/230/240 VAC
    Voltage Rangle81-145 VAC / 162-290 VAC162-290 VAC
    Frequency Range60/50 Hz (Auto sensing)
    OUTPUT
    Output Voltage110/120 VAC or 220/230/240 VAC220/230/240 VAC
    AC Voltage Regulation(Batt Mode)± 10%
    Frequency Range(Batt Mode)50 Hz or 60 Hz ± 1 Hz
    Trensfer TimeTypical 2-6 ms
    Waveform(Batt Mode)Simulated Sinewave
    BATTERY
    Battery Type&Nunber 12V/4.5AH*112V/7AH*112V/9AH*112V/7AH*212V/9AH*212V/9AH*212V/10AH*2
    Typical Recharge Time 4-6 hours recover to 90% capacity
    PROTECTION
    Full Protection Overload, discharge, and overcharge protection
    INDICATORS
    LCD ModelInput voltage, output voltage, battery capacity, load level and UPS status
    LCD ModelAC ModeGreen lightingGreen lightingGreen lighting and 4 LEDs indlicating load level
    Battery ModeGreen flashingYellow flashingGreen lighting and 4 LEDs indlicating battery capacity
    FauitN/ARed lightingRed lighting
    ALARM
    Battery Mode Sounding every 10 seconds
    Low Battery Sounding every second
    Overload Sounding every 0.5 second
    Fault Continuously sounding
    PHYSICAL
    LCD ModelDimension,D*W*H(mm)300*101*142320*130*182390*147*205
    Net Weight(kgs)3.74.457.810.410.615.1
    LCD ModelDimension,D*W*H(mm)279*101*142320*130*182390*147*205
    Net Weight(kgs)3.554.24.98.210.41115.1
    ENVIRONMENT
    Humidity 0-90 % RH @ 0- 40°C (Non-condensing)
    Noise Level Less than 40dBLess than 45dB
    Product speciffcations are subject to change without further notice.
